ER300 series all electric single servo cnc turret punch press
Main transmission adopts direct drive servo motor, which retains the advantage of simple and reliable structure as mechanical transmission, at the same time, servo transmission has a better performance than hydraulic transmission. ES300 series punch press has the characteristics of high-efficiency, energy-saving, low-noise, high-accuracy, and can realize many processes like cutting, forming, rolling, lettering and so on.
The punching force is 300KN, the max. sheet size can be fabricated is 5000x1250mm (with one re-positioning), five-axis machining (X, Y, T, C, A). The core of the Windows operating system and CNCKAD application. CAD two-dimensional graphics programming; Batch drag and drop processing of files in DXF, DWG or IGES format, direct nesting
Servo system- Japan Panasonic AC servo motor and servo amplifier unit; Punching power-Nanjing ESTUN all electric servo motor; Adopt O-frame steel frame welding frame; line guider and ball screw choose Germany REXROTH.
